Detailed Introduction

Application of GSYA Mobile Grille Cleaning Machine

It has multiple uses and low investment, mainly suitable for water plants and large-scale rainwater and sewage pumping stations.

Working principle

Using three wire ropes for traction, a desktop mobile type, a rake bucket, and fixed bars, debris is intercepted on the bars and salvaged by the rake bucket. Then, the rake motor works to open the rake bucket, and a preset scraper scrapes the debris into the press machine. The trolley is moved to the second station to complete the cleaning process, until n stations are completed.

characteristic

The machine movement adopts two control modes, automatic or manual, and runs smoothly;

The movement of the trolley, the lifting and opening of the rake bucket are three independent driving systems that operate according to the electrical program settings;

The mobile trolley is equipped with limit devices, positioning mechanisms, and induction switches, ensuring safe and reliable operation;

model selection

GSYA - □□ Note: GSYA mobile grid cleaning machine, □ equipment width mm, □ grid spacing mm.
